Compact car camper ammeter with maximum peak memory and alarm with pressure gauge relay kit
€189.00
Tax included
Compact ammeter with max peak memory and settable alarm relay that allows you to view and monitor the current absorption of our vehicle. Tool cComplete with everything you need
SECURE ENCRYPTED PAYMENTS
ORDER ALWAYS TRACKABLE
SAFE AND PROTECT PROTOXIDE PACKAGING
- Very precise and very fast ammeter that allows you to view the real-time absorption of our vehicle even with a decimal figure for example 245.1 amperes.
- Kit complete with battery clamp, battery connection cable and sensor for current reading complete with everything. We installed it in about 45-60 minutes, so installation is very quick and simplified.
- Incredibly compact dimensions, in fact it allows recessed installation with a 45x22 mm hole, with a depth of 70mm,
- With the simple touch of a button it is possible to recall the maximum peak reached with simultaneous switching on of the high intensity blue LED which will show the maximum peak reached and will remain in memory even after turning off the ignition, as it writes directly to the internal non-volatile flash memory ! ---- UNIQUE FUNCTION ----
- Internal relay that can be activated based on the set point set by us, which will allow you to activate or deactivate any activator upon reaching it together with a red LED on the display . 3AMP
- Extremely fast sampling instrument with 4 measurements per second.
- 12 DC power supply and consumption of less than 2 watts
- Total accuracy 0.2 %
- Built-in dimensions 48X24X75mm
- Brightness reduction function by pressing a button
- There is also a stabilized 5 volt output for powering any sensors
- Complete with ProtoXide installation instructions and photos and technical support for a quick exemplified installation, which few know how to correctly connect an ammeter on vehicles.
Data sheet
- Supply
- 12 Volt
- Joint compensation
- Si
- Display
- 4 cifre
- Probe cable length
- Silicone 3 metri
- Precision
- 0.2%
- Depth
- 75mm
- Output 0-5 volts
- Si
- Relay output
- Si
